0004998: Support graphical formulas

ID	Project	Category	View Status	Date Submitted	Last Update

0004998	CaseTalk Modeler	Diagrams	public	2025-02-18 11:16	2025-03-31 17:00

Reporter	BCP Software	Assigned To	BCP Software
Priority	normal	Severity	feature	Reproducibility	have not tried
Status	resolved	Resolution	fixed
Platform	Intel	OS	Windows	OS Version	11
Target Version	14.x	Fixed in Version	14.2

Summary	0004998: Support graphical formulas
Description	Support for formulas being printed in a graphical form.
Additional Information	Generated diagrams should also be provided. https://github.com/yuzutech/kroki/issues/442
Tags	No tags attached.

CaseTalk Edition	unknown

BCP Software 2025-02-18 13:11 administrator ~0005486 Last edited: 2025-02-18 13:13	Provide annotation with the similar format: `<math> f(y) = sqrt(x+5) </math>` XML Copy The <Math> elements can be placed in any annotation or paragraph text.

BCP Software 2025-02-18 13:51 administrator ~0005487	Supporting the AsciiMath syntax: http://asciimath.org/

BCP Software 2025-02-18 14:09 administrator ~0005488	PlantUML_Math.png (105,435 bytes) PlantUML_Math.png (105,435 bytes)

BCP Software 2025-03-29 09:36 administrator ~0005523	In the Fact View it already shows as a graphical formula.

BCP Software 2025-03-31 17:00 administrator ~0005527	Plain formulas are supported in a syntax similar to excel worksheet formulas. More documentation will follow. (For PlantUML these are automatically reformatted to fit the AsciiMath syntax.)
